加工优势

1. 采用龙门式结构，双工位工作

2. 导轨采用全封闭防护，环保安全

3. 无接触式焊接，无机械应力损伤，热影响小

4. 同轴CCD实时监视系统可清晰观察焊点效果

5. 带温度反馈系统，可以控制焊点温度

6. 带CCD自动识别定位系统，可以自动校正位置偏差，保证焊接精度

7. 可以焊接各式PCB的DIP类型加工，咪头及VCM马达等产品

ADVANTAGES

1. Using gantry structure, double-station work.

2. All-enclosed protection for guide rail, environmental protection and safety.

3. Contactless welding, no mechanical stress damage, small heat effect.

4. Coaxial CCD real-time monitoring system can clearly observe the effect of solder joints.

5. With temperature feedback system, solder joint temperature can be controlled.

6. Automatic identification and positioning system with CCD can automatically correct position deviation and ensure welding accuracy.

7. It can be used to weld DIP type processing of various PCBs, microphones and VCM motors, etc

技术参数：                                            Technical parameters:
激光功率：100W（可选）                     Laser power: 100W (optional)
运动控制：PLC                                      Motion control: PLC
重复精度：±0.02mm                            Repeat accuracy: ±0.02mm
焊接范围：300*300mm                       Welding range: 300*300mm
送丝规格：0.3-1.2mm                          Wire feeding specification: 0.3-1.2mm
焊接效率：约1s/point                           Welding efficiency: about 1s/point
电源要求：AC220V 50H                        Power requirements: AC220V 50Hz

应用行业及客户样品效果展示：
光通讯，手机数码，3C电子，智能制造，汽车电子，电声行业，仪表仪器，航空航天等 。

Application industry and customer sample effect display:
Optical communication, mobile phone digital, 3C electronics, intelligent manufacturing, automotive electronics, electroacoustic industry, instrumentation, aerospace, etc

加工效果EFFECTS
